Introduce Zoom callers

StudioPro allows you to easily introduce Zoom callers into your productions. To introduce Zoom callers, the Zoom application is required. Please note, access to 52.19.175.155 with ports 443 & 4000 UDP/TCP are required to use Zoom in StudioPro.



Configuring Zoom calling

Navigate to the Zoom website and install the Zoom application. Once installed. locate and open the Zoom application from the desktop. Once open, you will need to login to an existing Zoom account or register. It is strongly recommended that a new account is registered and dedicated to introducing Zoom callers into StudioPro.




Adding Zoom callers into your scenes

To add a Zoom caller you will firstly need to create a new Zoom meeting. To do this, launch Zoom and select New Meeting. Once your meeting has been created, select Participants from the control bar, then select Invite. Copy the invite link, and invite your Zoom contributors.


Depending on your Zoom settings, your guests may need to be approved to join your meeting. To approve select Participants from the control bar, then select Admit next to your waiting guests.

Once your Zoom callers have joined your Zoom meeting, you will need to add these as a source into the STS410. Within the scene you would like to add your Zoom caller, select the plus-icon.png icon to add a new source, locate ‘Zoom Caller’ then click Add Source.


Select Create new, then enter a friendly name for your source, e.g Zoom 1, then click OK.


When the Properties dialog box opens, you will be prompted to enter the Meeting URL. Navigate back to your Zoom meeting, select Participants > Invite > Copy Invite Link.


Returning back to the StudioPro interface, paste the copied link into Meeting URL then click OK. A new user called ‘StudioPro’ will now join your meeting, please note that depending on your Zoom settings the StudioPro may need to be admitted into the meeting.


Once joined you will see all users displayed within the call. Next select your Zoom source, then click Interact.


Within the pop-out window, double click the Zoom caller you would like to focus on to enlarge them, then double click the large preview to set full screen.


This process would need to be repeated to add all callers to your production.




When adding a single Zoom caller to multiple scenes, it is good practice to add your existing sources rather than creating a new source. To do this, within your scene, select the plus-icon.png icon, locate Zoom Caller then click Add Source. Now select Add Existing and then select the name of the source added previously. This will keep all your previously configured settings and selected source for your caller.



Something to be aware of is that every time you bring in a Zoom caller source you bring in the whole Zoom call audio. So be sure to mute all but one of the audio tracks.





You'll also want to send a program return back to your Zoom guests. This can be achieved using the Virtual Camera feature.

Open the Settings window and navigate to Advanced




In Return Output Configuration, set one of the outputs Type to Virtual Camera, select the Video and Audio you want to send back to your Zoom guests. It is recommended that you set up up an Aux audio output which doesn't include the Zoom callers to send back to the call.




When you're happy with your settings, click Start




Now head back to Zoom and select the appropriate virtual cable for your video device, in this case Virtual Cable A.




And the same for the Audio/microphone device.




You have now successfully configured a video and audio return from StudioPro to your Zoom call.
